Skid sliding loader
Category:
Skid sliding loader
Chat with us now for a quick response.
Get expert sales advice within 12 hours.
Keyword:
Skid sliding loader
PRODUCT DETAILS
Skid sliding loader
|
Item |
Parameter |
Item |
Parameter |
|
Engine |
Double-cylinder B&S engine |
Max.operation height mm |
2450 |
|
Rate power( kW) |
17.2 |
Max pin height (mm) |
1870 |
|
Rotation speed(rpm) |
3600 |
Overall height (mm) |
1350 |
|
Cylinder QTY |
2 |
Maximum height of bucket flat (mm) |
1810 |
|
Air intake mode |
Nature |
No attached total length (mm) |
1680 |
|
Displacement cc |
627 |
Total length with standard bucket (mm) |
2206 |
|
Emission standards |
EPA |
Maximum height unload angle° |
34 |
|
Rote loading Kg |
300 |
Unloading height (mm) |
1510 |
|
Max.loading Kg |
400 |
Unload distance(mm) |
450 |
|
The greatest rising power kN |
450 |
The angle at which the bucket turns over on the ground ° |
27 |
|
Bucket volume m³ |
0.12 |
The bucket turns over at the highest angle |
114 |
|
Walking speed km/h |
0-6 |
Wheelbase(mm) |
850 |
|
Three tasks s |
9 |
Ground clearance (mm) |
150 |
|
Working system pressure bar |
17-21 |
Tail length(mm) |
280 |
|
Oil tank capacity L |
25 |
Wheel distance(mm) |
720 |
|
Operation weight Kg |
1200 |
Machine width(mm) |
960 |
|
Wheel model |
17*72 |
Bucket width (mm) |
1000 |
OUR FACTOYR
Tai'an Oubosen Machinery Co., Ltd. was established in 2015 and is a high-tech enterprise that integrates research and development, production, sales, and service. The company has a modern production base and advanced production equipment; Having multiple professional technical personnel provides strong support for the continuous updating and quality improvement of the company's products.
INVENTORY
The company is mainly committed to the research and development, production, and sales of engineering machinery, agricultural machinery, construction machinery, and environmental protection machinery; The main products include small excavators, mini track transport vehicles, self loading small track mixer trucks, slip machines, football field grass planters, remote-controlled solar powered installation elevators, remote-controlled electric lawn mowers, self-propelled lawn mowers, and other products.
EQUIPMENT
Customer visits
COMMON PROBLEM
Can we provide drawings or prototypes for you to develop and promise exclusive sales?
We accept customization with drawings or samples to achieve true co-development, and promise to adhere to targeted sales of customized products.
What other additional services will we offer?
Professional advertising videos. We have our own photographers and video editors to offer you professional customized advertising videos.
We have our own graphic design team that can provide you with professional high-definition images for your advertisement.
We have a large professional technical team, and we will designate one engineer and salesman to help you improve sales and after-sales efficiency.
