350L Full hydraulic self-loading concrete mixer
Category:
Concrete mixer-full hydraulic
Chat with us now for a quick response.
Get expert sales advice within 12 hours.
Keyword:
350L Full hydraulic self-loading concrete mixer
PRODUCT DETAILS
350L Full hydraulic self-loading concrete mixer
The fully hydraulic 350L concrete mixer is a highly efficient and automated concrete mixing equipment suitable for construction sites, bridge projects, and precast concrete factories.
Hydraulic Drive System
- Power Unit: A hydraulic motor directly drives the mixing shaft, reducing mechanical transmission losses and improving energy efficiency.
- Direction Control: The hydraulic system enables drum rotation in both directions—forward for mixing and reverse for discharging—ensuring easy operation.
Teachnicale date:
| 1 | Engine | Koop186 diesel engine9HP 4-stroke air cooler |
| 2 | System | Full hydraulic |
| 3 | Unloading ways | Hydraulic |
| 4 | Shovel volume | 0.11m³ |
| 5 | Hydraulic pump | Series gear pump(4ccX2) 3600RPM |
| 6 | Working pressure | Max 180bar |
| 7 | Flow rate | 8.0L |
| 8 | Motor torque | 645Nm 180bar |
| 9 | Feeding volume of mixer | ≤380L |
| 10 | Discharge volume of mixer | ≤280L |
| 11 | Output capacity/H | ≤1120L |
| 12 | Mixer size | Φ760*880 |
| 13 | Overall size | 2550×1120×1650mm |
| 14 | Weight（N/G） | 610/670KG |
| 15 | Rubber crawler size | 150*60*44 |
| 16 | Touch length of rubber crawler | 900mm |
| 17 | Walking speed | 0-8KM |
| 18 | Ability to cross obstacles | Max 40° on slope vertical height200mm |
| 19 | Wading depth | 350mm |
| 20 | Package size | Plywood case：2100×1080×1600mm |
| 21 | Container (20/40 high) | 6 units (naked)/12 units (naked) |
Detail:
On site:
Package ways:
OUR FACTOYR
Tai'an Oubosen Machinery Co., Ltd. was established in 2015 and is a high-tech enterprise that integrates research and development, production, sales, and service. The company has a modern production base and advanced production equipment; Having multiple professional technical personnel provides strong support for the continuous updating and quality improvement of the company's products.
INVENTORY
The company is mainly committed to the research and development, production, and sales of engineering machinery, agricultural machinery, construction machinery, and environmental protection machinery; The main products include small excavators, mini track transport vehicles, self loading small track mixer trucks, slip machines, football field grass planters, remote-controlled solar powered installation elevators, remote-controlled electric lawn mowers, self-propelled lawn mowers, and other products.
EQUIPMENT
Customer visits
COMMON PROBLEM
Can we provide drawings or prototypes for you to develop and promise exclusive sales?
We accept customization with drawings or samples to achieve true co-development, and promise to adhere to targeted sales of customized products.
What other additional services will we offer?
Professional advertising videos. We have our own photographers and video editors to offer you professional customized advertising videos.
We have our own graphic design team that can provide you with professional high-definition images for your advertisement.
We have a large professional technical team, and we will designate one engineer and salesman to help you improve sales and after-sales efficiency.
