Crawler Mixer 350L Mechanical gearbox
Category:
Rubber crawler concrete mixer
Concrete mixer-gearbox
Get expert sales advice within 12 hours.
Keyword:
Crawler Mixer 350L Mechanical gearbox
PRODUCT DETAILS
| engine | Standard configuration: Changchai 178 diesel engine 5.5HP 4 rush the wind cold 3600 rpm H/d H/d |
| Optional engine: Belle Tong EPA 10HP 4 Chongye Cold 3600 Ring/D | |
| gearbox | GL-10 File: 3F+R No parking brakes |
| Operation Method | Manual Manual Ring |
| Unloading method | Hydraulic dilute bidirectional manual control valve operation |
| Fighting volume | 0.08m³ |
| Mixing tank adds materials | ≥450L |
| Mixing tanks out of the disappear | ≤300L |
| Stir quality | ≤500公斤 |
| Stir -mixing tank size | Φ760*820 / Φ660*920 (non -customized) |
| Overall size | 2500 (2800 buckets on the ground) ×1080×1500mm |
| Track specifications | 150x60x44 |
| Track grounding length | 900mm |
| Loading weight | 600KG on flat ground, 400KG on 30° slope |
| Walking speed | 0-8km |
| more obstacle ability | Maximum 30° slope, vertical height 200mm |
| Water -related depth | 300mm |
| Packaging Size | Single wooden box packaging: 2100×1080×1600 |
| Weight (net weight/hairy weight) | 580kg/650kg |
| Container (20/40 high) | 6 (nude)/12 (naked) |
|
Remarks: 1.Optional simple seat |
|
OUR FACTOYR
Tai'an Oubosen Machinery Co., Ltd. was established in 2015 and is a high-tech enterprise that integrates research and development, production, sales, and service. The company has a modern production base and advanced production equipment; Having multiple professional technical personnel provides strong support for the continuous updating and quality improvement of the company's products.
INVENTORY
The company is mainly committed to the research and development, production, and sales of engineering machinery, agricultural machinery, construction machinery, and environmental protection machinery; The main products include small excavators, mini track transport vehicles, self loading small track mixer trucks, slip machines, football field grass planters, remote-controlled solar powered installation elevators, remote-controlled electric lawn mowers, self-propelled lawn mowers, and other products.
EQUIPMENT
Customer visits
COMMON PROBLEM
Can we provide drawings or prototypes for you to develop and promise exclusive sales?
We accept customization with drawings or samples to achieve true co-development, and promise to adhere to targeted sales of customized products.
What other additional services will we offer?
Professional advertising videos. We have our own photographers and video editors to offer you professional customized advertising videos.
We have our own graphic design team that can provide you with professional high-definition images for your advertisement.
We have a large professional technical team, and we will designate one engineer and salesman to help you improve sales and after-sales efficiency.
